Corner Tube Boiler – 2 Sets (75 t/h) (China, 2017-2018)
GB-compliant corner tube boiler twin units with sequential delivery and coordinated commissioning for continuous power generation.
Project Gallery
Detailed views of the corner tube boiler twin-unit project
Corner Tube Boiler (2 Sets, 75t/h each)
Twin-unit configuration for power generation
Four-Corner Furnace Design
Optimized combustion pattern for efficiency
Membrane Water-Wall Panels
High-efficiency heat absorption surfaces
Superheater Assembly
Precision-engineered steam heating elements
Boiler Drum
High-pressure vessel with internal components
Factory Production
Quality-controlled manufacturing process
On-Site Installation
Sequential installation with phased approach
Project Handover
Performance validation and operational training
Project Snapshot
Core project information at a glance
Project Information
| Field | Value |
|---|---|
| Product | Corner Tube Boiler – 2 Sets (75 t/h each) |
| Design Code | GB |
| Country / Region | China |
| Year | 2017, 2018 |
| Industry / Application | Power Plant |
| Scope Type | Twin-Unit Boiler System Supply |
Client Core Needs
Key requirements for twin-unit deployment
GB Code Compliance
Full compliance with Chinese GB standards for domestic market
Sequential Delivery
Phased installation across 2017-2018 to meet project milestones
Uniform Design Standards
Identical twin units for simplified operation and maintenance
ORL Solution
Comprehensive twin-unit delivery approach
GB-Compliant Design & Manufacturing
Full adherence to Chinese national standards
Standardized Twin-Unit Configuration
Identical design for operational efficiency
Synchronized Manufacturing Schedule
Coordinated production for sequential delivery
Quality Consistency Across Units
Unified inspection and testing protocols
Phased Installation Support
On-site technical supervision for each unit
Comprehensive Documentation Package
Complete records for both units with GB compliance
Quality & Documentation Package
Comprehensive quality assurance for twin-unit projects
Material Certificate / EN 10204 3.1
(as required)
Full Traceability
(heat no. tracking)
Dimensional Inspection Report
Comprehensive measurements
Hydro Test Record
(if applicable)
GB Compliance Verification
Code compliance documentation
ITP / QCP Support
(if required)
Third-party Inspection Support
(if required)
Duplicate Documentation Sets
Separate packages for each unit
